RICOH RICOH IP CW2200

Wide Format Color

Meet your wide-format printing needs with the IP CW2200. Produce CAD drawings, poster designs, construction plans and other large format documents. Print high-quality, durable prints that can be viewed on site, in any weather — our waterproof GEL-Jet™ technology uses inks that are smudge free and UV resistant. Stay productive with an intuitive and easy to use 10.1" Smart Operation Panel. Restrict access and protect confidential information with a range of security measures built into the system. Plus, save time with the automatic paper roll setting.

Please Note:

Selected items that require additional options will automatically be selected.
Some items are not compatible with other options. Non-compatible options will be disabled from selection.

Step 1: Main Unit

	Item/Description	Tips	Item #	Thumbnail
	IP CW2200IP CW2200 Output Speed (D-Size): 3.8-ppm B&W and 2.1-ppm Color Maximum Power Consumption: Less than 160W Maximum Print Width: 36" (914mm) Maximum Print Length: 108' (33m) Power Requirements: 120 – 127V/60Hz, 15A Weight: 220 lbs. (100 kg) W × D × H (inches): 54.5 × 26 × 44 W × D × H (mm): 1,384 × 660 × 1,118 Note: IP CW2200 ships with enough ink to prime the machine for start up only. Additional ink is required for use upon install.	No tooltip available.	408521
	IP CW2200 B UnitIP CW2200 B Unit Required to complete your configuration.	No tooltip available.	408524

Step 2: Paper Handling

	Item/Description	Tips	Item #	Thumbnail
	Roll Unit RU6570Roll Unit RU6570 Increases the roll capacity from standard 1 roll to 2 rolls total. Weight: 31.9 lbs. (14.5 kg) W × D × H (inches): 43.6 × 15.7 × 17 W × D × H (mm): 1,107 × 399 × 432 Note: By choosing this option, Roll Holder Unit Type M23 will be automatically added.	Roll Unit RU6570 The item(s) below will be selected if this item is selected: Roll Holder Unit Type M23 (404834)	418976
	Roll Holder Unit Type M23Roll Holder Unit Type M23 Additional roll holders allow for easy paper handling when multiple paper sizes are being used. Weight: 3.3 lbs. (1.5 kg) W × D × H (inches): 43.6 × 15.7 × 17 W × D × H (mm): 1,107 × 399 × 432 Note: By choosing this option, Roll Unit RU6570 will be automatically added.	Roll Holder Unit Type M23 The item(s) below will be selected if this item is selected: Roll Unit RU6570 (418976)	404834

Step 3: Print Options

Item/Description	Tips	Item #
IEEE 802.11a/g/n Interface Unit Type M19IEEE 802.11a/g/n Interface Unit Type M19 Required for wireless network access.	No tooltip available.	417493
RICOH PrintTool Ver. 2RICOH PrintTool Ver. 2 The PrintTool Ver. 2 is a client/server application that gives users the ability to submit batched jobs to a centralized job management application. The management application has the capability to hold the job for later reprints, if needed. The PrintTool includes a Graphical User Interface (GUI) for users to submit batched jobs consisting of multiple formats, a Direct Tool that can be used to generate shared folders with preprogrammed settings for submission and a Copy Tool (installed by Service).	No tooltip available.	409547
PrintCopy Tool Option Type D 2021PrintCopy Tool Option Type D 2021 PrintCopyTool Option Type D 2021 allows for the use of DWG, DXF and DWF formats. Note: RICOH PrintTool Ver. 2 must be selected to add this option.	PrintCopy Tool Option Type D 2021 At least one of the item(s) below must be selected to be able to select this item: RICOH PrintTool Ver. 2 (409547)	409501

Step 4: Security & Miscellaneous Accessories

	Item/Description	Tips	Item #	Thumbnail
	ESP XG-PCS-15DESP XG-PCS-15D Provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products.	No tooltip available.	006428MIU

Please Note:

For maximum performance and yield, we recommend using genuine Ricoh Family Group-branded parts and supplies.

Step 5: Supplies

Item/Description	Tips	Item #
Print Cartridge Black MP CW2200Print Cartridge Black MP CW2200 Unit Packaging: 1 Bottle (200 ml.) Yield: 4,452 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841720
Print Cartridge Cyan MP CW2200Print Cartridge Cyan MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,748 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841721
Print Cartridge Magenta MP CW2200Print Cartridge Magenta MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,732 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841722
Print Cartridge Yellow MP CW2200Print Cartridge Yellow MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,726 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841723

Complete Your Configuration

Start Over

Standard Features Include

10.1" Smart Operation Panel
Color Printing
4 GB RAM
320 GB HDD
USB 2.0/USB Host/SD Slot

SDK Customization
Print-from USB Drive/SD Card
1200 dpi print resolution
Inkjet Print Technology
Adobe^® Postscript3
HDD Encryption

Show More Features

Current Configuration

W × D × H 0" × 0" × 0"
0mm × 0mm × 0mm

View Selected Items
