IM CW2200 SYSTEM CONFIGURATOR

Visit Ricoh-USA.com

Ricoh Online System Configurator Tool

Choose a Model• Select Options • Save, Print or Email

RICOH RICOH IM CW2200

Wide Format Color

Streamline your workflow with an all-in-one wide-format printer that delivers a modern, more productive way to work. Designed for AEC and CAD professionals to thrive, the IM CW2200 is solution-ready for smarter collaboration in today’s hyper-connected world. Print up to 2.1 ppm color and 3.8 ppm B&W. Stay productive with an intuitive and easy to use 10.1" Smart Operation Panel. Produce up to 1200 x 1200 dpi resolution. Plus, increase efficiency with the automatic paper roll setting and support for mobile capabilities.

Please Note:

Selected items that require additional options will automatically be selected.
Some items are not compatible with other options. Non-compatible options will be disabled from selection.

Step 1: Main Unit

	Item/Description	Tips	Item #	Thumbnail
	IM CW2200IM CW2200 Output Speed (D-Size): 3.8-ppm B&W and 2.1-ppm Color Maximum Power Consumption: Less than 180W Maximum Print Width: 36" (914mm) Maximum Print Length: 108' (33m) Power Requirements: 120 – 127V/60Hz, 15A Weight: 265 lbs. (120 kg) W × D × H (inches): 54.5 × 26.6 × 48 W × D × H (mm): 1,384 × 676 × 1,219 Note: IM CW2200 ships with enough ink to prime the machine for start up only. Additional ink is required for use upon install.	No tooltip available.	418971
	IM CW2200 B UnitIM CW2200 B Unit Required to complete your configuration.	No tooltip available.	418974

Step 2: Paper Handling

	Item/Description	Tips	Item #	Thumbnail
	Roll Unit RU6570Roll Unit RU6570 Increases the roll capacity from standard 1 roll to 2 rolls total. Weight: 31.9 lbs. (14.5 kg) W × D × H (inches): 43.6 × 15.7 × 17 W × D × H (mm): 1,107 × 399 × 432 Note: By choosing this option, Roll Holder Unit Type M23 will be automatically added.	Roll Unit RU6570 The item(s) below will be selected if this item is selected: Roll Holder Unit Type M23 (404834)	418976
	Roll Holder Unit Type M23Roll Holder Unit Type M23 Additional roll holders allow for easy paper handling when multiple paper sizes are being used. Weight: 3.3 lbs. (1.5 kg) W × D × H (inches): 43.6 × 15.7 × 17 W × D × H (mm): 1,107 × 399 × 432 Note: By choosing this option, Roll Unit RU6570 will be automatically added.	Roll Holder Unit Type M23 The item(s) below will be selected if this item is selected: Roll Unit RU6570 (418976)	404834

Step 3: Print/Scan Options

Item/Description	Tips	Item #
File Format Converter Type M23File Format Converter Type M23 Required when paper length is more than 2,774mm (109.2").	No tooltip available.	404835
OCR Unit Type M13OCR Unit Type M13 Required for OCR scanned documents. This function embeds invisible text on scanned images of PDFs and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders and external media (USB/SD).	No tooltip available.	417430
IEEE 802.11a/g/n Interface Unit Type M19IEEE 802.11a/g/n Interface Unit Type M19 Required for wireless network access.	No tooltip available.	417493
RICOH PrintTool Ver. 2RICOH PrintTool Ver. 2 The PrintTool Ver. 2 is a client/server application that gives users the ability to submit batched jobs to a centralized job management application. The management application has the capability to hold the job for later reprints, if needed. The PrintTool includes a Graphical User Interface (GUI) for users to submit batched jobs consisting of multiple formats, a Direct Tool that can be used to generate shared folders with preprogrammed settings for submission and a Copy Tool (installed by Service) that can be used to scan from any color scanner to the Central Management Application and/or a color printer available on the network.	No tooltip available.	409547
PrintCopy Tool Option Type D 2021PrintCopy Tool Option Type D 2021 PrintCopyTool Option Type D 2021 allows for the use of DWG, DXF and DWF formats. Note: RICOH PrintTool Ver. 2 must be selected to add this option.	PrintCopy Tool Option Type D 2021 At least one of the item(s) below must be selected to be able to select this item: RICOH PrintTool Ver. 2 (409547)	409501

Step 4: Security & Miscellaneous Accessories

	Item/Description	Tips	Item #	Thumbnail
	ESP XG-PCS-15DESP XG-PCS-15D Provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products.	No tooltip available.	006428MIU

Please Note:

For maximum performance and yield, we recommend using genuine Ricoh Family Group-branded parts and supplies.

Step 5: Supplies

Item/Description	Tips	Item #
Print Cartridge Black MP CW2200Print Cartridge Black MP CW2200 Unit Packaging: 1 Bottle (200 ml.) Yield: 4,452 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841720
Print Cartridge Cyan MP CW2200Print Cartridge Cyan MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,748 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841721
Print Cartridge Magenta MP CW2200Print Cartridge Magenta MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,732 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841722
Print Cartridge Yellow MP CW2200Print Cartridge Yellow MP CW2200 Unit Packaging: 1 Bottle (100 ml.) Yield: 2,726 sq. ft. Based on A1Y, 6% chart, 20% Color DV Ratio. Note: The ink that comes with the mainframe is a starter kit only. Additional ink is required for continued use of the equipment.	No tooltip available.	841723

Complete Your Configuration

Start Over

Standard Features Include

10.1" Smart Operation Panel
Color Copying, Printing and Scanning
4 GB RAM
320 GB HDD
USB 2.0/USB Host/SD Slot

SDK Customization
Scan-to/Print-from USB Drive/SD Card
1200 dpi print resolution
Inkjet Print Technology
Adobe^® Postscript3
HDD Encryption

Show More Features

Current Configuration

W × D × H 0" × 0" × 0"
0mm × 0mm × 0mm

View Selected Items
