RICOH P 501/P 501TL/P 502

Printer B&W

To get the most out of your documents and data you need a device that enables efficient, simple and secure document management. A device that meets your business needs, from outstanding print output to seamless connectivity. And for that, you can rely on the RICOH P 501/P 501TL/P 502 black-and-white printers. With these Value Devices you can print with outstanding reliability, sustainability and productivity.

Please Note:

Selected items that require additional options will automatically be selected.
Some items are not compatible with other options; non-compatible options will be disabled from selection.

Step 1: Main Unit

Item/Description	Tips	Item #
P 501P 501 Output Speed (Letter): 45-ppm Average Monthly Volume: 3,000 impressions/month Maximum Monthly Volume: 10,000 impressions/month Power Requirements: 120-127V/12A, 60Hz Ships with Starter Toner that yields 6,000 B&W prints (ISO/IEC 19752). Weight: 42.55 lbs. (19.3 kg) W × D × H (inches): 14.76 × 16.22 × 12.24 W × D × H (mm): 375 × 412 × 311	P 501 The item(s) below are not compatible with this option and cannot be selected: Print Cartridge IM 430 (419078)	418082
P 501TLP 501TL Healthcare model with built-in locking and label enhanced paper tray. Output Speed (Letter): 45-ppm Average Monthly Volume: 3,000 impressions/month Maximum Monthly Volume: 10,000 impressions/month Power Requirements: 120-127V/12A, 60Hz Ships with Starter Toner that yields 6,000 B&W prints (ISO/IEC 19752). Weight: 42.55 lbs. (19.3 kg) W × D × H (inches): 14.76 × 16.22 × 12.24 W × D × H (mm): 375 × 412 × 311	P 501TL The item(s) below are not compatible with this option and cannot be selected: Print Cartridge IM 430 (419078)	418941
P 502P 502 Output Speed (Letter): 45-ppm Average Monthly Volume: 3,000 impressions/month Maximum Monthly Volume: 10,000 impressions/month Power Requirements: 120-127V/12A, 60Hz Ships with Starter Toner that yields 17,400 B&W prints (ISO/IEC 19752). Weight: 42.55 lbs. (19.3 kg) W × D × H (inches): 14.76 × 16.22 × 12.24 W × D × H (mm): 375 × 412 × 311	P 502 The item(s) below are not compatible with this option and cannot be selected: Print Cartridge P 501H (419083) Drum Unit P 501 (419095) Maintenance Kit P 501 (418095)	418494

Please Note:

Up to 3 paper feed units may be added to the mainframe for a maximum paper capacity of 2,100 sheets.

Step 2: Paper Tray & Optional Accessories

Item/Description	Tips	Item #
Paper Feed Unit PB1110Paper Feed Unit PB1110 Provides an additional 250 sheets. Paper sizes up to 8.5" x 14". Paper weights up to 14 lb. Bond/120 lb. Index. Weight: 10.58 lbs. (4.8 kg) W × D × H (inches): 14.6 × 15.5 × 3.8 W × D × H (mm): 371 × 394 × 97	No tooltip available.	418080
Paper Feed Unit PB1110TLPaper Feed Unit PB1110TL A locking and label enhanced paper feed unit. Provides an additional 250 sheets. Paper sizes up to 8.5" x 14". Paper weights up to 14 lb. Bond/120 lb. Index. Weight: 10.58 lbs. (4.8 kg) W × D × H (inches): 14.6 × 15.5 × 3.8 W × D × H (mm): 371 × 394 × 97	No tooltip available.	418219
Paper Feed Unit PB1120Paper Feed Unit PB1120 Provides an additional 500 sheets. Paper sizes up to 8.5" x 14". Paper weights up to 14 lb. Bond/120 lb. Index. Weight: 12.13 lbs. (5.5 kg) W × D × H (inches): 14.6 × 15.5 × 4.9 W × D × H (mm): 371 × 394 × 124	No tooltip available.	418081
Paper Feed Unit PB1120TLPaper Feed Unit PB1120TL A locking and label enhanced paper feed unit. Provides an additional 500 sheets. Paper sizes up to 8.5" x 14". Paper weights up to 14 lb. Bond/120 lb. Index. Weight: 12.13 lbs. (5.5 kg) W × D × H (inches): 14.6 × 15.5 × 4.9 W × D × H (mm): 371 × 394 × 124	No tooltip available.	418218
Caster Table Type M34Caster Table Type M34 Provides a platform with wheels to easily move the device. Can only be configured with either one, two or three optional paper feed units. Note: Caster Table Type M34 or Medium Cabinet Type P must be added to the configuration when three optional paper feed units are installed.	Caster Table Type M34 The item(s) below are not compatible with this option and cannot be selected: Medium Cabinet Type P (52005) Tall Cabinet Type Q (52006)	52007
Medium Cabinet Type PMedium Cabinet Type P Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper. Can only be configured with either two or three optional paper feed units. Weight: 35.3 lbs. (16 kg) W × D × H (inches): 14.6 × 15.4 × 11.2 W × D × H (mm): 371 × 391 × 284 Note: Medium Cabinet Type P or Caster Table Type M34 must be added to the configuration when three optional paper feed units are installed.	Medium Cabinet Type P The item(s) below are not compatible with this option and cannot be selected: Caster Table Type M34 (52007) Tall Cabinet Type Q (52006)	52005
Tall Cabinet Type QTall Cabinet Type Q Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper. Can only be configured with either the standard configuration or one optional paper feed unit. Weight: 49.8 lbs. (18.5 kg) W × D × H (inches): 14.6 × 15.4 × 20.8 W × D × H (mm): 371 × 391 × 528	Tall Cabinet Type Q The item(s) below are not compatible with this option and cannot be selected: Caster Table Type M34 (52007) Medium Cabinet Type P (52005)	52006

Step 3: Print Options

	Item/Description	Tips	Item #	Thumbnail
Network Environment/Connectivity
	IEEE802.11 Interface Unit Type M24IEEE802.11 Interface Unit Type M24 Allows the device to connect to the network over WiFi. Useful for temporary sites and locations where cabling is impractical.	No tooltip available.	407863
	PostScript3 Unit Type P18PostScript3 Unit Type P18 Genuine Adobe^® PostScript^®3™. Recommended for printing more complex B&W and PDF files. The P 501, P 501TL and P 502 come with standard PostScript3 Emulation. This option is available for customers who require True Adobe^® workflows like Photoshop^®, Illustrator^® and PDF/X as well as additional font support. When enabled on the printer, the standard PostScript3 Emulation will be disabled.	No tooltip available.	418441
Printing Features
	Item/Description	Tips	Item #	Thumbnail
	Hard Disk Drive Option Type P18Hard Disk Drive Option Type P18 The Hard Disk Drive (HDD) is required for Locked/Hold/Stored Print. Data Overwrite and Encryption are available when the HDD is installed.	No tooltip available.	418438
	IPDS Unit Type P18IPDS Unit Type P18 For use in AS/400 environments. Note: Hard Disk Drive Option Type P18 must be selected to add this option.	IPDS Unit Type P18 At least one of the item(s) below must be selected to be able to select this item: Hard Disk Drive Option Type P18 (418438)	418444

Step 4: Security & Miscellaneous Accessories

	Item/Description	Tips	Item #	Thumbnail
	Power Filter with Inrush, Surge and Noise Protection 120V/15APower Filter with Inrush, Surge and Noise Protection 120V/15A Power filter provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of power protection products to minimize potential electrical interference with products. Note: Power Filter with Inrush, Surge and Noise Protection 120V/15A cannot be installed with Single Outlet Wall Mount Power Filter 120V/15A.	Power Filter with Inrush, Surge and Noise Protection 120V/15A The item(s) below are not compatible with this option and cannot be selected: Single Outlet Wall Mount Power Filter 120V/15A (W250-15-120)	W1500-15-120
	Single Outlet Wall Mount Power Filter 120V/15ASingle Outlet Wall Mount Power Filter 120V/15A Wall-mounted power filter provides multi-stage power surge protection and noise filtering for output devices. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products. Note: Single Outlet Wall Mount Power Filter 120V/15A cannot be installed with Power Filter with Inrush, Surge and Noise Protection 120V/15A.	Single Outlet Wall Mount Power Filter 120V/15A The item(s) below are not compatible with this option and cannot be selected: Power Filter with Inrush, Surge and Noise Protection 120V/15A (W1500-15-120)	W250-15-120

Step 5: Supplies

Item/Description	Tips	Item #
Print Cartridge IM 430Print Cartridge IM 430 Black toner for the P 502. Targeted Yield: 17,400 prints/cartridge. Declared yield value in accordance with ISO/IEC 19752. Actual yields may vary based on types of images printed and other factors. Note: 1. A Starter Toner cartridge is included with the mainframe, but we recommend ordering another for replenishment. 2. P 502 must be selected to add this supply.	Print Cartridge IM 430 At least one of the item(s) below must be selected to be able to select this item: P 502 (418494)	419078
Print Cartridge P 501HPrint Cartridge P 501H High yield black toner for the P 501 or P 501TL. Targeted Yield: 14,000 prints/cartridge. Declared yield value in accordance with ISO/IEC 19752. Actual yields may vary based on types of images printed and other factors. Note: 1. A Starter Toner cartridge is included with the mainframe, but we recommend ordering another for replenishment. 2. P 501 or P 501TL must be selected to add this supply.	Print Cartridge P 501H At least one of the item(s) below must be selected to be able to select this item: P 501 (418082) P 501TL (418941)	419083
Drum Unit P 501Drum Unit P 501 Drum unit for the P 501 or P 501TL. Targeted Yield: 40,000 prints. Declared yield value in accordance with ISO/IEC 19752. Actual yields may vary based on types of images printed and other factors. Note: 1. A Starter Toner cartridge is included with the mainframe, but we recommend ordering another for replenishment. 2. P 501 or P 501TL must be selected to add this supply.	Drum Unit P 501 At least one of the item(s) below must be selected to be able to select this item: P 501 (418082) P 501TL (418941)	419095
Maintenance Kit P 501Maintenance Kit P 501 Maintenance kit for the P 501 or P 501TL. Targeted Yield: 120,000 prints. Declared yield value in accordance with ISO/IEC 19752. Actual yields may vary based on types of images printed and other factors. Note: 1. A Starter Toner cartridge is included with the mainframe, but we recommend ordering another for replenishment. 2. P 501 or P 501TL must be selected to add this supply.	Maintenance Kit P 501 At least one of the item(s) below must be selected to be able to select this item: P 501 (418082) P 501TL (418941)	418095

Complete Your Configuration

Start Over

Standard Features Include

4-line LCD Panel
500-Sheet Paper Tray
100-Sheet Bypass Tray
Integrated Duplex
Mobile Printing

PostScript3 Emulation
2 GB RAM

Show More Features

Current Configuration

W × D × H 0" × 0" × 0"
0mm × 0mm × 0mm
