RICOH P 800

Printer B&W

The P 800 black and white printer was designed to handle the most demanding workgroup print requirements. It can be positioned at the very heart of your operation. Compact, easy to use and utterly reliable, it produces high quality print communication quickly and offers a host of standard or optional security features. This energy efficient printer supports mobile printing and can be configured with up to 2,600 sheets.

Please Note:

Selected items that require additional options will automatically be selected.
Some items are not compatible with other options. Non-compatible options will be disabled from selection.

Step 1: Main Unit

	Item/Description	Tips	Item #	Thumbnail
	P 800P 800 Output Speed (Letter): 57-ppm Average Monthly Volume: 4,000 impressions/month Maximum Monthly Volume: 16,600 impressions/month Power Requirements: 120~127V, 60Hz Ships with Starter Toner that yields 10,000 B&W prints (ISO/IEC 19752). Weight: 39.7 lbs. (18 kg) W × D × H (inches): 16.5 × 16.1 × 13.6 W × D × H (mm): 419 × 409 × 345	No tooltip available.	418469

Please Note:

Up to 4 paper feed units may be added to the mainframe for a maximum paper capacity of 2,600 sheets.

Step 2: Paper Tray & Optional Accessories

Item/Description	Tips	Item #
Paper Feed Unit PB1160Paper Feed Unit PB1160 Provides an additional 500 sheets. Paper sizes up to 8.5" x 14". Paper weights up to 58 lb. Bond/120 lb. Index. Weight: 8.8 lbs. (4 kg) W × D × H (inches): 15 × 16.1 × 4.8 W × D × H (mm): 381 × 409 × 122	No tooltip available.	418475
Caster Table Type ZCaster Table Type Z The caster table must be added to the configuration when four optional paper feed units are installed. It provides a platform with wheels to easily move the device. Note: 1. Caster Table Type Z cannot be installed with the base unit, one, two or three paper feed units, Medium Cabinet Type T or Tall Cabinet Type U. 2. Caster Table Type Z can only be installed when the system is configured with four optional paper feed units. If four paper feed units are not selected then this option cannot be added to your configuration.	Caster Table Type Z The item(s) below are not compatible with this option and cannot be selected: Medium Cabinet Type T (52642) Tall Cabinet Type U (52652)	22633
Medium Cabinet Type TMedium Cabinet Type T Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper. Can only be configured with two or three optional paper feed units. Weight: 13.7 lbs. (6.2 kg) W × D × H (inches): 15 × 16.2 × 10 W × D × H (mm): 381 × 411 × 254 Note: 1. Medium Cabinet Type T cannot be installed with the base unit, one paper feed unit, four paper feed units, Caster Table Type Z or Tall Cabinet Type U. 2. Medium Cabinet Type T can only be installed when the system is configured with two or three optional paper feed units. If two or three optional paper feed units are not selected then this option cannot be added to your configuration.	Medium Cabinet Type T The item(s) below are not compatible with this option and cannot be selected: Caster Table Type Z (22633) Tall Cabinet Type U (52652)	52642
Tall Cabinet Type UTall Cabinet Type U Raises the height of the system while providing businesses with a convenient option for the storage of supplies and paper. Recommended for a floor-standing configuration with either the base unit or one optional paper feed unit added. Weight: 22.5 lbs. (10.2 kg) W × D × H (inches): 15 × 16.2 × 20 W × D × H (mm): 381 × 411 × 508 Note: 1. Tall Cabinet Type U cannot be installed with more than one additional paper feed unit, Caster Table Type Z or Medium Cabinet Type T. 2. Tall Cabinet Type U can only be installed with the base unit or one optional paper feed unit. If two, three or four optional paper feed units are selected then this option cannot be added to your configuration. 3. A longer lead time is required when ordering this item. Expected delivery is 30+ days from order acknowledgement date.	Tall Cabinet Type U The item(s) below are not compatible with this option and cannot be selected: Caster Table Type Z (22633) Medium Cabinet Type T (52642)	52652

Step 3: Print Options

	Item/Description	Tips	Item #	Thumbnail
Network Environment/Connectivity
	IEEE802.11 Interface Unit Type M24IEEE802.11 Interface Unit Type M24 Allows the device to connect to the network over WiFi. Useful for temporary sites and locations where cabling is impractical.	No tooltip available.	407863
	PostScript3 Unit Type P19PostScript3 Unit Type P19 Genuine Adobe^® PostScript^®3™. Recommended for printing more complex B&W and PDF files. The P 800 comes with standard PostScript3 Emulation. This option is available for customers who require True Adobe^® workflows like Photoshop^®, Illustrator^® and PDF/X as well as additional font support. When enabled on the printer, the standard PostScript3 Emulation will be disabled.	No tooltip available.	418538
Printing Features
	Item/Description	Tips	Item #	Thumbnail
	Hard Disk Drive Option Type P8Hard Disk Drive Option Type P8 The 320 GB Hard Disk Drive (HDD) is required for Locked/Hold/Stored Print. Data Overwrite and Encryption are available when the HDD is installed.	No tooltip available.	418912
Embedded Software Support
	Item/Description	Tips	Item #	Thumbnail
	IPDS Unit Type M40IPDS Unit Type M40 For use in AS/400 environments. As a genuine Intelligent Printer Data Stream (IPDS) solution built on original IBM source code, our IPDS option provides more accurate interpretation of IPDS data. That means less errors and faster file processing than emulations. Plus, as an IBM partner your customers can be assured of fast problem resolution and timely upgrades. Note: Hard Disk Drive Option Type P8 must be selected to add this option.	IPDS Unit Type M40 At least one of the item(s) below must be selected to be able to select this item: Hard Disk Drive Option Type P8 (418912)	418516

Step 4: Security & Miscellaneous Accessories

	Item/Description	Tips	Item #	Thumbnail
	Single Outlet Wall Mount Power Filter 120V/15ASingle Outlet Wall Mount Power Filter 120V/15A Wall-mounted power filter provides multi-stage power surge protection and noise filtering for output devices. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products. Note: Single Outlet Wall Mount Power Filter 120V/15A cannot be installed with Power Filter with Inrush, Surge and Noise Protection 120V/15A.	Single Outlet Wall Mount Power Filter 120V/15A The item(s) below are not compatible with this option and cannot be selected: Power Filter with Inrush, Surge and Noise Protection 120V/15A (W1500-15-120)	W250-15-120
	Power Filter with Inrush, Surge and Noise Protection 120V/15APower Filter with Inrush, Surge and Noise Protection 120V/15A Power filter provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of power protection products to minimize potential electrical interference with products. Note: Power Filter with Inrush, Surge and Noise Protection 120V/15A cannot be installed with Single Outlet Wall Mount Power Filter 120V/15A.	Power Filter with Inrush, Surge and Noise Protection 120V/15A The item(s) below are not compatible with this option and cannot be selected: Single Outlet Wall Mount Power Filter 120V/15A (W250-15-120)	W1500-15-120

Step 5: Supplies

Item/Description	Tips	Item #
Print Cartridge IM 600Print Cartridge IM 600 Black toner for the P 800. Targeted Yield: 25,500 prints/cartridge. Declared yield value in accordance with ISO/IEC 19752. Actual yields may vary based on types of images printed and other factors. Note: 1. A Starter Toner cartridge is included with the mainframe, but we recommend ordering another for replenishment. 2. P 800 must be selected to add this option. 3. Toner cartridges include a replacement waste toner bottle.	No tooltip available.	418477
Feed Roller MP 601Feed Roller MP 601 Feed roller option for the main unit. Targeted Yield: 500,000 prints.	No tooltip available.	408049
Feed Roller MP 601PBFeed Roller MP 601PB Feed roller option for the paper feed unit. Targeted Yield: 500,000 prints. Note: Paper Feed Unit PB1160 must be selected to add this option.	Feed Roller MP 601PB At least one of the item(s) below must be selected to be able to select this item: Paper Feed Unit PB1160 (418475)	408050

Complete Your Configuration

Start Over

Standard Features Include

4-line LCD Panel
500-Sheet Paper Tray
100-Sheet Bypass Tray
Integrated Duplex
2 GB RAM

PostScript3 Emulation
Gigabit Ethernet
USB 2.0 Connectivity
Mobile Printing

Show More Features

Current Configuration

W × D × H 0" × 0" × 0"
0mm × 0mm × 0mm

View Selected Items
