RICOH SP 8400DN

Printer B&W

The SP 8400DN black and white printer is ideal for businesses that require high-speed output for high-volume applications, including medical records, statements, legal documents, and more. The system features our Workstyle Innovation Technology and comes standard with PostScript3 Emulation, PDF Direct Print Emulation, and a Smart Operation Panel for a user-friendly, tablet-like experience. Organizations can further enhance their workflow with system options that include a status light indicator, a wide range of finishing, and support for mobile printing. Plus, new smart support capabilities can be enabled to help provide better system uptime and availability.

Please Note:

Selected items that require additional options will automatically be selected.
Some items are not compatible with other options; non-compatible options will be disabled from selection.

Step 1: Main Unit

	Item/Description	Tips	Item #	Thumbnail
	SP 8400DNSP 8400DN Output Speed (Letter): 60-ppm Recommended Monthly Volume: 12,000 to 53,000 impressions/month Maximum Monthly Volume: 53,000 impressions/month Power Requirements: 120-127V, 60Hz Weight: 125.7 lbs. (57 kg) W × D × H (inches): 23.1 × 25.7 × 28.3 W × D × H (mm): 587 × 653 × 719	No tooltip available.	408244

Step 2: Paper Tray & Optional Accessories

Item/Description	Tips	Item #
Paper Feed Unit PB3240Paper Feed Unit PB3240 Provides an additional 1,100 sheets. Paper Sizes up to 11.69" x 17". Paper Weights up to 80 lb. Bond/166 lb. Index (300 g/m²). Weight: 48.5 lbs. (22 kg) W × D × H (inches): 23.1 × 27 × 9.7 W × D × H (mm): 587 × 686 × 246 Note: Paper Feed Unit PB3240 cannot be installed with Paper Feed LCIT PB3260 or Cabinet Type F.	Paper Feed Unit PB3240 The item(s) below are not compatible with this option and cannot be selected: Paper Feed LCIT PB3260 (408116) Cabinet Type F (100478FNG)	408112
Paper Feed LCIT PB3260Paper Feed LCIT PB3260 Provides an additional 2,000 sheets. Paper Sizes up to 8.5" x 11"/A4. Paper Weights up to 80 lb. Bond/166 lb. Index (300 g/m²). Weight: 48.5 lbs. (22 kg) W × D × H (inches): 23.1 × 27 × 9.7 W × D × H (mm): 587 × 686 × 246 Note: Paper Feed LCIT PB3260 cannot be installed with Paper Feed Unit PB3240 or Cabinet Type F.	Paper Feed LCIT PB3260 The item(s) below are not compatible with this option and cannot be selected: Paper Feed Unit PB3240 (408112) Cabinet Type F (100478FNG)	408116
LCIT RT3030LCIT RT3030 Provides an additional 1,500 sheets. Paper Sizes up to 8.5" x 11"/A4. Paper Weights up to 80 lb. Bond/166 lb. Index (300 g/m²). Weight: 22 lbs. (9.8 kg) W × D × H (inches): 13.4 × 21.4 × 11.4 W × D × H (mm): 340 × 544 × 290 Note: LCIT RT3030 must be configured with either Paper Feed Unit PB3240 or Paper Feed LCIT PB3260.	LCIT RT3030 At least one of the item(s) below must be selected to be able to select this item: Paper Feed Unit PB3240 (408112) Paper Feed LCIT PB3260 (408116)	416548
Cabinet Type FCabinet Type F Provides businesses with a convenient option for the storage of supplies and paper. Can only be configured with the standard configuration. Weight: 32.3 lbs. (14.7 kg) W × D × H (inches): 23.1 × 26.7 × 10 W × D × H (mm): 587 × 678 × 254 Note: Cabinet Type F cannot be installed with Paper Feed Unit PB3240, Paper Feed LCIT PB3260, or LCIT RT3030.	Cabinet Type F The item(s) below are not compatible with this option and cannot be selected: Paper Feed Unit PB3240 (408112) Paper Feed LCIT PB3260 (408116) LCIT RT3030 (416548)	100478FNG

Step 3: Output & Finishing Options

	Item/Description	Tips	Item #	Thumbnail
External
	Finisher SR3210Finisher SR3210 1,000-sheet Finisher. For offices that produce collated and stapled sets of documents, the SR3210 helps shorten production time. It offers 50-sheet, multi-position stapling, mixed sized stapling, optional hole-punching, and shift-sort collating, as well as a staple-less binding capability of up to 5 sheets. Supports Paper Sizes up to 12" x 18". Weight: 60 lbs. (27 kg) W × D × H (inches): 22.2 × 24.4 × 37.8 W × D × H (mm): 564 × 620 × 960 Note: 1. Paper Feed Unit PB3240, Paper Feed LCIT PB3260, or Cabinet Type F must be selected to add this option. 2. Bridge Unit BU3070 must be installed to add this option. 3. Finisher SR3210 cannot be installed with Finisher SR3230 or any related options.	Finisher SR3210 At least one of the item(s) below must be selected to be able to select this item: Paper Feed Unit PB3240 (408112) Paper Feed LCIT PB3260 (408116) Cabinet Type F (100478FNG) The item(s) below are not compatible with this option and cannot be selected: Finisher SR3230 (417487) Punch Unit PU3060 NA (416612) Output Jogger Unit Type M25 (417630)	417483
	Finisher SR3230Finisher SR3230 3,000-sheet Finisher. For offices that produce collated and stapled sets of documents, the SR3230 helps shorten production time. It offers 50-sheet, multi-position stapling, mixed sized stapling, optional hole-punching, and shift-sort collating. Supports Paper Sizes up to 12" x 18". Weight: 74 lbs. (33.5 kg) W × D × H (inches): 25.9 × 24.1 × 37.8 W × D × H (mm): 658 × 612 × 960 Note: 1. Paper Feed Unit PB3240, Paper Feed LCIT PB3260, or Cabinet Type F must be selected to add this option. 2. Bridge Unit BU3070 must be installed to add this option. 3. Finisher SR3230 cannot be installed with Finisher SR3210 or any related options.	Finisher SR3230 At least one of the item(s) below must be selected to be able to select this item: Paper Feed Unit PB3240 (408112) Paper Feed LCIT PB3260 (408116) Cabinet Type F (100478FNG) The item(s) below are not compatible with this option and cannot be selected: Finisher SR3210 (417483) Punch Unit PU3050 NA (416609)	417487
	Bridge Unit BU3070Bridge Unit BU3070 A required accessory when an external finisher is not configured with the Multi-fold unit. The Bridge Unit transports pages from the standard exit area into a Finisher for inline stapling or hole-punching. Note: This option must be installed when adding Finisher SR3210 or Finisher SR3230.	Bridge Unit BU3070 At least one of the item(s) below must be selected to be able to select this item: Finisher SR3210 (417483) Finisher SR3230 (417487)	417587
Hole Punching Options
	Item/Description	Tips	Item #	Thumbnail
	Punch Unit PU3050 NAPunch Unit PU3050 NA Optional hole punching for the Finisher SR3210. Supports Paper Sizes up to 11" x 17". Note: Finisher SR3210 must be selected to add this option.	Punch Unit PU3050 NA At least one of the item(s) below must be selected to be able to select this item: Finisher SR3210 (417483)	416609
	Punch Unit PU3060 NAPunch Unit PU3060 NA Optional hole punching for the Finisher SR3230. Supports Paper Sizes up to 11" x 17". Note: Finisher SR3230 must be selected to add this option.	Punch Unit PU3060 NA At least one of the item(s) below must be selected to be able to select this item: Finisher SR3230 (417487)	416612
Output Jogger Options
	Item/Description	Tips	Item #	Thumbnail
	Output Jogger Unit Type M25Output Jogger Unit Type M25 Aligns and stacks output delivered from the Finisher SR3230. W × D × H (inches): 21.9 × 21.4 × 19.9 W × D × H (mm): 556 × 544 × 505 Note: Finisher SR3230 must be selected to add this option.	Output Jogger Unit Type M25 At least one of the item(s) below must be selected to be able to select this item: Finisher SR3230 (417487)	417630

Step 4: Print Options

	Item/Description	Tips	Item #	Thumbnail
Network Environment
	IEEE 802.11a/g/n Interface Unit Type M19IEEE 802.11a/g/n Interface Unit Type M19 Allows MFP device to connect to the network over WiFi. Useful for temporary sites and locations where cabling is impractical.	No tooltip available.	417493
	PostScript 3 Unit Type P13PostScript 3 Unit Type P13 Genuine Adobe^® PostScript^®3™. Recommended for printing more complex B&W and PDF files. The SP 8400DN comes with standard PostScript3 Emulation and PDF Direct Print Emulation. This option is available for customers who require True Adobe^® workflows like Photoshop^®, Illustrator^® and PDF/X as well as additional font support. When enabled on the MFP, the standard PostScript3 Emulation will be disabled.	No tooltip available.	408097
Printing Features
	Item/Description	Tips	Item #	Thumbnail
	HDD Option Type P13HDD Option Type P13 Required for Sample Print, Locked/Secure Print, HDD Hold & Storage Print, Stored Print, Stored Print (Shared) and Cover Sheet features.	No tooltip available.	408382
	IPDS Unit Type P13IPDS Unit Type P13 For use in AS/400 environments. As a genuine Intelligent Printer Data Stream (IPDS) solution built on original IBM source code, our IPDS option provides more accurate interpretation of IPDS data. That means less errors and faster file processing than emulations. Plus, as an IBM partner your customers can be assured of fast problem resolution and timely upgrades.	No tooltip available.	408076

Step 5: Security & Miscellaneous Accessories

	Item/Description	Tips	Item #	Thumbnail
	Attention Light AL3000Attention Light AL3000 The attention light visually alerts operators to changes in system status for prompt attention. Weight: .66 lbs. (.3 kg) W × D × H (inches): 4 × 4.1 × 23.9 W × D × H (mm): 102 × 104 × 607	No tooltip available.	407964
	ESP XG-PCS-15DESP XG-PCS-15D Provides multi-stage power protection as well as line conditioning. Our Advanced Technical Support (ATS) recommends the use of Power Protection products to minimize potential electrical interference with products.	No tooltip available.	006428MIU

Step 6: Supplies

Item/Description	Tips	Item #
Toner SP 8400AToner SP 8400A Black Toner Cartridge. Yield = 51,000 pages Declared yield values in accordance with ISO 19798. Actual yields may vary based on images printed and other factors. Note: A Starter Toner cartridge, which yields 51,000 pages, is included with the mainframe, but we recommend ordering another for replenishment.	No tooltip available.	821276
Maintenance Kit AMaintenance Kit A Includes Drum Unit, Transfer Unit, and Waste Toner Bottle. Yield = 160,000 pages Actual yields may vary based on images printed and other factors.	No tooltip available.	408107
Maintenance Kit BMaintenance Kit B Includes Fusing Unit. Yield = 320,000 pages Actual yields may vary based on images printed and other factors.	No tooltip available.	408108
Staple Set Type TStaple Set Type T Unit Packaging = 5,000 per Crtg. (1 Crtg/Ctn) Yield: 5,000 staples Note: Finisher SR3210 or Finisher SR3230 must be selected to add this option.	Staple Set Type T At least one of the item(s) below must be selected to be able to select this item: Finisher SR3210 (417483) Finisher SR3230 (417487)	415009
Staple Refill Type TStaple Refill Type T Unit Packaging = 5,000 per Crtg. (2 Crtg/Ctn) Yield: 10,000 staples Note: Finisher SR3210 or Finisher SR3230 must be selected to add this option.	Staple Refill Type T At least one of the item(s) below must be selected to be able to select this item: Finisher SR3210 (417483) Finisher SR3230 (417487)	415010

Complete Your Configuration

Start Over

Standard Features Include

10.1" Smart Operation Panel
2 x 550-Sheet Paper Tray
100-Sheet Bypass Tray
2 GB Memory
PostScript 3 Emulation

PDF Direct Emulation
Gigabit Ethernet (10Base-T/100Base-TX/1000Base-T)
Starter Toner

Show More Features

Current Configuration

W × D × H 0" × 0" × 0"
0mm × 0mm × 0mm

View Selected Items
